Steel Tape Armoured Control Cable CU/PVC/STA/PVC NYBY KVV22

APPLICATION

Steel Tape Armoured Control Cable CU/PVC/STA/PVC NYBY KVV22‌ is a type of ‌armored control cable‌ designed for fixed installations in environments requiring mechanical protection, such as cable trenches, direct burial, and indoor applications with high mechanical stress‌.
It is commonly used in ‌industrial plants, power stations, and automation systems‌ where protection against mechanical damage is essential‌

CONSTRUCTION

Conductor

Circular solid copper conductor(A) or circular stranded copper conductor(B)
Insulation

Polyvinyl chloride (PVC)
Filler

Polypropylene(PP) mesh filling rope
Armouring

Galvanized steel tape
Outer sheath

Polyvinyl chloride (PVC)

Steel Tape Armoured Control Cable CU/PVC/STA/PVC NYBY KVV22

CHARACTERISTIC

Voltage Rating Uo/U: 450/750V
Temperature Rating
Maximum operating temperature of conductor:+70℃
Operating ambient temperature: -15℃~+45℃
Cable laying temperature:Not less than 0℃(When the ambient temperature is below 0℃, the cable should be preheated.)
Minimum Bending Radius: 12D (D is the actual outer diameter of the cable)

SPECIFICATION

Specs mm²	Conductor diameter mm	Nominal thickness of insulation mm	Nominal thickness of sheath mm	Approximate outer diameter of cable mm	Approximate cable weight kg/km
2×0.5	0.85	0.6	1.5	10.6	156.5
2×0.5(B)	0.90	0.6	1.5	10.7	159.2
2×0.75	1.02	0.6	1.5	11.0	168.8
2×0.75(B)	1.10	0.6	1.5	11.1	172.9
2×1	1.16	0.6	1.5	11.2	179.7
2×1(B)	1.29	0.6	1.5	11.5	186.2
2×1.5	1.41	0.7	1.5	12.2	211.5
2×1.5(B)	1.56	0.7	1.5	12.5	219.2
2×2.5	1.76	0.8	1.5	13.4	260.4
2×2.5(B)	2.04	0.8	1.5	13.8	272.6
2×4	2.22	0.8	1.5	14.3	310.7
2×4(B)	2.55	0.8	1.5	14.9	25.1
2×6	2.74	0.8	1.5	15.3	371.7
2×6(B)	3.10	0.8	1.5	16.0	388.9
2×10	4.00	1.0	1.5	18.6	533.9
3×0.5	0.85	0.6	1.5	11.0	171.2
3×0.5(B)	0.90	0.6	1.5	11.1	174.4
3×0.75	1.02	0.6	1.5	11.3	186.5
3×0.75(B)	1.10	0.6	1.5	11.5	191.4
3×1	1.16	0.6	1.5	11.6	200.6
3×1(B)	1.29	0.6	1.5	11.9	208.0
3×1.5	1.41	0.7	1.5	12.6	240.0
3×1.5(B)	1.56	0.7	1.5	12.9	248.8
3×2.5	1.76	0.8	1.5	13.9	02.4
3×2.5(B)	2.04	0.8	1.5	14.4	316.5
3×4	2.22	0.8	1.5	15.0	369.0
3×4(B)	2.55	0.8	1.5	15.5	385.7
3×6	2.74	0.8	1.5	16.0	451.0
3×6(B)	3.10	0.8	1.5	16.7	470.8
3×10	4.00	1.0	1.5	19.6	662.2
4×0.5	0.85	0.6	1.5	11.5	190.5
4×0.5(B)	0.90	0.6	1.5	11.6	194.2
4×0.75	1.02	0.6	1.5	11.9	209.6
4×0.75(B)	1.10	0.6	1.5	12.1	215.0
4×1	1.16	0.6	1.5	12.3	226.9
4×1(B)	1.29	0.6	1.5	12.6	235.4
4×1.5	1.41	0.7	1.5	13.4	275.1
4×1.5(B)	1.56	0.7	1.5	13.7	285.6
4×2.5	1.76	0.8	1.5	14.9	352.8
